Butterfly Valves

High-Performance Butterfly Valves for Efficient Flow Control

At Veltora Valve Pvt. Ltd., we manufacture premium-quality Industrial Butterfly Valves engineered for reliable isolation and precise flow control across a wide range of industrial applications. Designed with a compact quarter-turn mechanism, our butterfly valves offer fast operation, lightweight construction, excellent sealing performance, and minimal maintenance, making them an ideal solution for modern process industries.

VELTORA Butterfly Valves are engineered to provide reliable flow control and dependable shut-off in a wide range of industrial applications. Featuring a compact quarter-turn design, these valves offer fast operation, lightweight construction, and excellent sealing performance, making them an ideal choice for systems requiring efficient flow regulation and isolation. Their space-saving design and low operating torque ensure easy installation, reduced maintenance, and long-lasting performance.

Manufactured from premium-quality materials, VELTORA Butterfly Valves are suitable for handling water, oil, gas, steam, chemicals, slurry, and other industrial process media. Available in wafer, lug, and flanged designs, as well as multiple sizes, pressure classes, seat materials, and actuator options, our butterfly valves are designed to meet the demanding requirements of modern industrial piping systems.

Body Materials
Cast Iron (GG25, GGG40, GGG50)
DuctileIron,CarbonSteel (ASTM A216 WCB, WCC)
Stainless Steel (ASTM A351 CF8, CF8M, CF3, CF3M)
Duplex Stainless Steel (ASTM A182 F51 / UNS S31803, F60 / UNS S32205)
Super Duplex Stainless Steel (ASTM A182 F53 / UNS S32750, F55 / UNS S32760)
Disc Materials

Stainless Steel,Duplex Stainless Steel,Aluminium Bronze,Monel,Hastelloy,Titanium,Nickel Alloy

Seat Materials

EPDM,NBR,Viton (FKM),PTFE,RPTFE,Silicone,Neoprene,Metal Seat (High Temperature Applications)

Design Standards

PI 609,MSS SP-67,EN 593,ASME B16.34,ISO 5752,BS 5155

End Connection Options

Wafer Type,Lug Type,Double Flanged Type,U-Type,Grooved End (On Request)

Compatible with

ANSI Flanges,DIN Flanges,BS Flanges,JIS Flanges

Pressure Rating

N10,PN16,ANSI Class 150,ANSI Class 300

Size Range

2" (DN50) to 72" (DN1800)

Testing Standards

API 598,ISO 5208,EN 12266-1,MSS SP-61

Inspection Includes

Hydrostatic Shell Test,Seat Leakage Test,Air Leakage Test,Torque Performance Test,Visual & Dimensional Inspection,Material Traceability Verification,Positive Material Identification (PMI) – On Request,Ultrasonic Testing (UT) – On Request,Radiographic Testing (RT) – On Request,Magnetic Particle Inspection (MPI) – On Request,Dye Penetrant Testing (DPT) – On Request

Key Features
Applications
Why Choose VELTORA Butterfly Valves?

VELTORA Butterfly Valves are manufactured to international quality standards, delivering exceptional flow control, reliable sealing, and outstanding durability. Designed for efficient operation and long-term reliability, our valves help reduce operating costs, improve process efficiency, and ensure consistent performance in demanding industrial environments. Whether for isolation or flow regulation, VELTORA Butterfly Valves provide a dependable solution for diverse industrial applications.
