Material Range
Body Materials
| Carbon Steel |
(ASTM A216 WCB, WCC, LCB) |
| Stainless Steel |
(ASTM A351 CF8, CF8M, CF3, CF3M) |
| Forged Carbon Steel |
(ASTM A105, LF2) |
| Forged Stainless Steel |
(ASTM A182 F304, F304L, F316, F316L) |
| Duplex Stainless Steel |
(ASTM A182 F51 / UNS S31803, F60 / UNS S32205) |
| Super Duplex Stainless Steel |
(ASTM A182 F53 / UNS S32750, F55 / UNS S32760) |
| Monel® |
(Alloy 400, K500) |
| Inconel® |
(Alloy 625, Alloy 718) |
| Hastelloy® |
(C22, C276) |
| Titanium |
(Grade 2, Grade 5) |
| Alloy 20,Nickel 200 / 201, Other Exotic Alloys |
available on request |
Seat & Trim Materials
Stainless Steel, Stellite Hard-Faced Trim, PTFE, RPTFE, PEEK, Graphite, Metal Seat (High Temperature Applications)
ASME Section VIII, API 520, API 521, API 526, ASME B16.34, ASME B16.5, ISO 4126, PED 2014/68/EU (On Request)
Flanged End (RF / RTJ), Threaded End (NPT / BSP / BSPT), Socket Weld End (SW), Butt Weld End (BW), Customized End Connections Available
ANSI Class 150, ANSI Class 300, ANSI Class 600, ANSI Class 900, ANSI Class 1500, ANSI Class 2500, PN16, PN25, PN40, PN64, PN100
Available in sizes ranging from: ½" (DN15) to 12" (DN300)
Customized sizes and pressure settings are available to meet specific project requirements.
Testing Standards
API 527, API 598, ISO 4126, ASME Section VIII, MSS SP-61
Inspection & Testing Includes
Hydrostatic Shell Test, Seat Leakage Test, Set Pressure Calibration ,Blowdown Adjustment Test ,Pop Test, Reseating Pressure Verification, Pneumatic Functional Test, Visual & Dimensional Inspection, Material Traceability Verification, Positive Material Identification (PMI) – On Request, Radiographic Testing (RT), Ultrasonic Testing (UT), Magnetic Particle Inspection (MPI), and Dye Penetrant Testing (DPT) – Available on Request.
